Automated Single Channel Dual Channel Infusion Pump Tci Standard

Product Categories
SUCE (HONG KONG) IMPORT AND EXPORT LIMITED
Contact Now

Automated Single Channel Dual Channel Infusion Pump Tci Standard

Place of Origin : Guangdong, China

Brand Name : SUCE

Model Number : IS50

Packaging Details : standard package

Supply Ability : 5000 Set/Sets per Month

Price : $499.00 - $599.00/Sets

Certification : CE,ISO13485

MOQ : 1PC

Payment Terms : T/T, Western Union,Payoneer

Delivery Time : about 5 days

Power Source : Electricity, AC 100V~240V, 50/60Hz

Warranty : 1 Year

After-sale Service : Onsite Training

Material : Plastic

Shelf Life : 1years

Quality Certification : ce

Instrument classification : Class II

Safety standard : GB/T18830-2009

Product name : Double channel Syringe Pump

Special function : With drug library

Volume Limit : 0.1ml~9999.9ml

Flow Rate Accuracy : Within ±3% (after correct calibration)

Mechanical precision : Within ±2%

Total Injection Volume : 0.1ml~9999.9ml (0.1ml step)

KVO rate : 1ml/h

Fuse : F1AL/250/60V, 2pcs inside

IP Classification : IPX4

Port : guangzhou

Contact Now

Product Description

Automated single channel Double channel infusion pump tci standard with drug library IS50

Special function
With drug library
Rate:
50/60ml Syringe: 0.1ml/h～999.9ml/h (0.1ml/h step)
1,000ml/h～1,500ml/h (1ml/h step)
30ml Syringe: 0.1ml/h～900.0ml/h (0.1ml/h step)
20ml Syringe: 0.1ml/h～600.0ml/h (0.1ml/h step)
10ml Syringe: 0.1ml/h～300.0ml/h (0.1ml/h step)
Flow Rate Accuracy:
Within ±3% (after correct calibration)
Mechanical precision:
Within ±2%
Bolus Rate:
50/60ml Syringe: 1,200ml/h
30 ml Syringe: 720ml/h
20 ml Syringe: 480ml/h
10 ml Syringe: 240ml/h
Purge Rate:
50/60ml Syringe: 1,500ml/h
30ml Syringe: 900ml/h
20ml Syringe: 600ml/h
10ml Syringe: 300ml/h
Volume Limit:
0.1ml～999.9ml
Total Injection
Volume:
0.1ml～9999.9ml (0.1ml step)
Occlusion:
High: 800mmHg ±200mmHg (106.7kPa±26.7kPa
Medium: 50/600mmHg ±100mmHg (66.7kPa±13.3kPa
Low: 300mmHg ±100mmHg (40.7kPa±13.3kPa )
Alarms:
Injection soon finish, end of injection,occlusion, improperly installation of syringe, wrong setting, low battery, syringe loose
etc.
Power Source:
AC 100V～240V, 50/60Hz; Internal rechargeable Li battery, capacity≥1,600mAh, 4 hours internal battery backup
KVO rate:
1ml/h
Fuse:
F1AL/250/60V, 2pcs inside
Power Consumption:
30VA
IP Classification:
IPX1
Equipment Classification:
Class II, internal power supply, Type BF
Operating Condition:
Ambient temperature: +5℃～+40℃;
Relative humidity:
20～90%
Transport & Storage Condition:
Ambient temperature: -30℃～+55℃
Relative humidity:
≤95%
Dimension:
280mm (L) × 210mm (W) × 130mm (H)
Weight:
2.2kg (net weight)
Automated Single Channel Dual Channel Infusion Pump Tci Standard

Double channel Syringe Pump with drug library IS50

Drug Library.
Separate operation between the two single channels.
Three working modes: rate mode, time-volume mode, dosage-weight mode.
Automatically calibration and compatible with all standard syringes of 10ml~50ml..
Freely Stackable: Users can freely stack one syringe pump onto another to provide multiple Solutions, which have a wide range of
clinical applications.
Large LCD screen displays working status.
KVO and Bolus functions.
Save the last infusion rate automatically when there is unpredicatable switch off.
Transfer the message between the Nurse-call System and the pumps.
